ET1Z04EACC00
ET1Z04EACC00 ET1Z04EACC00 ET1Z04EACC00 ET1Z04EACC00 ET1Z04EACC00

Huawei Routers & Switches

ET1Z04EACC00

Part number: ET1Z04EACC00

On Request Unknown

Request Quote

Key specifications

Product Code ET1Z04EACC00
Packet Forwarding Rates 3,120 Mpps; 4,560 Mpps
Switching Capacity 4.88 Tbit/s; 16.08 Tbit/s
MPU Slots 2
SFU Slots 2
Service Card Slots 4
Energy Saving Energy Efficient Ethernet (802.3az)
Redundancy Design MPUs, SFUs, power supplies, and fan modules
Maximum Power Consumption of the Entire Equipment ≤ 2,200W
Installation The switch can be installed in an N66E or N68E cabinet, one cabinet for one chassis.
Dimensions (W x D x H) With cable management frames: 442 mm x 585 mm x 441.7 mm (17.4 in. x 23.0 in. x 17.39 in. (10 U)) Without cable management frames: 442 mm x 489 mm x 441.7 mm (17.4 in. x 19.3 in. x 17.39 in. (10 U))
Weight 60 kg (132.3 lb)
① Two MPUs
② Four service cards, including: ·Open Service Platform Unit ·1000M Interface Card ·GE/10GE Interface Card ·10GE Interface Card ·40GE Interface Card ·100GE Interface Card
③ Two SFUs
④ A pair of mounting brackets
⑤ Four power modules
⑥ Two CMUs
⑦ Front ESD jack
⑧ Cable management frames

Ordering information

ConditionUnknown
AvailabilityOn Request
WarrantyTested before shipping. 90-day warranty.
Lead timeTBD

Values marked TBD are pending confirmation and are not guessed.

Description

Brand: Huawei Model: ET1Z04EACC00 Detail: 02350MJA Huawei S12704 Enhanced Engine AC Bundle(Including Assembly Chassis*1,MPUA Main Board*1,SFUC Switch Fabric Unit*2,800W AC Power*2,Basic Software*1) Condition: Brand New Sealed Availability: IN STOCK
