S5700-28C-HI-AC
S5700-28C-HI-AC S5700-28C-HI-AC S5700-28C-HI-AC S5700-28C-HI-AC S5700-28C-HI-AC

Huawei Routers & Switches

S5700-28C-HI-AC

Part number: Card

On Request Unknown

Request Quote

Key specifications

Product Code S5700-28C-HI-AC
Ports 24 × 10/100/1,000 Base-T ports
Extended Slots 1 extended slot
Memory (RAM) 512 MB
Flash 64 MB
MAC Address Table Size 32 MAC
Subcard Supported 2 x 10 GE SFP+ Optional subcard 4 x 10 GE SFP+ Optional subcard 4 x 1,000 BASE-X
Voltage Required AC: Rated voltage range: 100V to 240V, 50/60 Hz Maximum voltage range: 90V to 264V, 50/60 Hz
Power Device Do double hot-swappable AC/DC power supplies
Power Consumption Operational <76 W
Forwarding performance 96 Mpps
Switching capacity 256 Gbit/s
Dimensions (W x D x H) 442 mm x 220 mm x 43.6 mm
Package Weight 5.1 kg
PoE Not supported
① Power module slot 1
③ ESD jack
⑤ ETH management port
⑦ Twenty-four 10/100/1000BASE-T ports
① Ground screw

Ordering information

ConditionUnknown
AvailabilityOn Request
WarrantyTested before shipping. 90-day warranty.
Lead timeTBD

Values marked TBD are pending confirmation and are not guessed.

Description

Brand: Huawei Model: S5700-28C-HI-AC Detail: 03021PED Huawei S5700 Series Switch S5700-28C-HI-AC(24 Ethernet 10/100/1000 ports,with 1 interface slot,with 170W AC power supply) Condition: Brand New Sealed Availability: IN STOCK
